How to Connect the Direct Drainage Hose on Your Tumble Dryer Before Installation

If you'd prefer to drain condensed water directly instead of using the water tank, follow

these steps to connect the direct drainage hose:

Step 1: Gather the Direct Drainage Hose

Your tumble dryer comes with a direct drainage hose supplied with the product. Make

sure you have this hose ready for installation.

Step 2: Locate the Water Tank Hose

At the bottom right side at the back of the dryer, you will find the water tank hose

connected to the pump. Take out the water tank hose to prepare for the direct drainage

hose connection.

Step 3: Connect the Direct Drainage Hose to the Pump

Connect one end of the direct drainage hose to the pump where the water tank hose was

previously connected. Ensure it is securely attached to prevent leaks.

Step 4: Connect the Other End to the Wastepipe

Connect the other end of the direct drainage hose to the wastepipe or drainage system.

Make sure it’s properly inserted and secure.

Step 5: Ensure Correct Drain Height and Hose Placement

The maximum height for the drainage should not exceed 80 cm. Also, check that the hose

is not tangled or kinked, as this could obstruct water flow and reduce efficiency.

By connecting the direct drainage hose, you can ensure that condensed water is drained

efficiently, removing the need to empty the water tank manually.
